Crawler crane
LR 1280

Due to their high level of mobility and excellent performance the wide range of possible applications starts with the common lifting and assembly jobs and ends with smaller clamshell and dragline applications. The Liebherr crawler cranes come up with outstanding advantages like superior load charts in most configurations, variety of possible configurations, quick and easy assembly, practical and cost-effective transportation, state of the art electronic system (based on CANBUS technology) including most modern power train management, online calculation of the maximum working load, high safety through redundant safety systems and high quality trough many proven specifications inherited from strong duty cycle crawler cranes. To further enhance the load capacities of the LR 1280 also a derrick system as well as a suspended counterweight is available.

max. lifting capacity
280 t at 4.3 m
Main boom, light/heavy
119.1 m / 90.2 m
Luffing jib
95 m
Fixed jib
26 m
Max. combination
150.1 m
Engine output
450 kW
Max. winch line pull 1. layer
215 kN
Travel speed
max. 1.4 km/h
Superstructure-/central ballast
85.5 t / 36 t
Derrick ballast
max. 120 t
